A Simple System with Dual Power: Lowering and Raising with Block and Tackle

The Block and Tackle System is a compact, pre-rigged solution designed for short-haul vertical rope access, confined space entry, and patient retrieval. It combines the benefits of mechanical advantage and continuous bidirectional control, eliminating the need to reset a progress capture device during haul cycles.

This system stands apart by offering a 4:1 mechanical advantage integrated into a dual-function hauling and lowering system, built for high-efficiency operations in tight vertical environments. The addition of a dedicated belay system ensures redundancy without interfering with operational flow.

System Layout and Components

At its core, the system uses a 4:1 pulley configuration, which multiplies the user’s input force for hauling while minimizing operator effort. This configuration is often suspended from a tripod, bipod, or artificial high directional, making it ideal for confined spaces and top-entry scenarios.

System Components:

• Haul/Lower System: Pre-configured with a mechanical advantage system using a TWIN RELEASE or equivalent

• Edge Protection: ROLLER COASTER to reduce friction and rope abrasion

• Connectors: AM’D, VULCAN, or OXAN carabiners for all anchor and pulley connections

• Ropes: Petzl AXIS, RAY 11, or VECTOR lines sized for device compatibility

• Belay System: Fully redundant, routed separately to activate only in case of main system failure

The operator controls both descent and haul via the mainline system while the belay team monitors the backup line independently.

Core Advantages of the Block and Tackle System

1. Designed for Confined Space and Vertical Entry

This system excels in vertical environments with limited access—such as tanks, silos, vaults, and manholes—where full-height systems aren’t practical. The compact footprint of the tripod plus integrated pulley setup allows responders to position directly over the access point.

2. Mechanical Advantage Built In

With a 4:1 ratio, the system reduces the force required to lift a load by a factor of four. This is critical when:

• Lifting a patient in a litter

• Extracting a rescuer

• Conducting work-at-height rope access where repeated lifting is needed

The user gains full raising power without external haul systems or directional pulleys.

3. Continuous Hauling Without Resets

The TWIN RELEASE allows uninterrupted raise-and-lower function. Unlike systems that require re-setting a rope grab or progress capture device between strokes, the TWIN RELEASE’s design enables smooth, continuous movement. This saves valuable time in both rescue and industrial scenarios where multiple lift cycles may occur.

4. Low Operator Load During Lowering

During descent, less than 25% of the total load is managed directly by the operator. The rest is modulated through mechanical advantage and device friction, which enhances control and reduces the risk of runaway lowers—especially useful with heavy litters or when descending into delicate environments.

5. Fast to Pre-Assemble and Deploy

Because it’s often pre-rigged or packed in a modular form, the Block and Tackle System is easy to set up on-site. The design allows teams to:

• Drop into position quickly

• Deploy from a kit without advanced assembly

• Maintain consistency across rescue teams and shifts

This ease of use reduces human error and accelerates on-scene setup—critical when time and safety are in tension.

Where the Block and Tackle System Shines

This system is best applied in scenarios such as:

• Confined Space Rescue
  Vertical entry into tanks, pits, shafts, or utility vaults where directional control and efficient lifting are essential.

• Industrial Rope Access
  Maintenance or inspection tasks requiring fast, controllable access and retrieval with minimal hardware reset.

• Short Vertical Hauls in Technical Rescue
  Where full mechanical advantage systems are impractical, but raising is still necessary.

• Backup-Limited Environments
  When team size is small, and hauling must be done by one or two rescuers using built-in mechanical support.

Summary: Efficiency and Control in a Tight Package

The Block and Tackle System is built around a clear mission: efficient vertical movement with minimal setup and maximum control. By integrating a 4:1 mechanical advantage, dual lowering and hauling capability, and redundant belay—all into a single portable kit—it becomes an ideal tool for:

• Rescue professionals in time-sensitive situations

• Rope access technicians managing confined space tasks

• Industrial teams needing repeatable, safe vertical access

Whether raising a worker or lowering into a vault, this system delivers reliability without complexity.

Peace on your Days

Lance
